Type: Seamless and Welded.

Size: ½” – 48” (Larger diameter available on request).

Wall Thickness : Schedule S-10 to S-XXS.

Special wall thicknesses or intermediate walls are also available in stock.

Dimension & Tolerances: ASME/ANSI B16.9, MSS SP 43, MSS SP 75

Material                                               Grade

ASME/ASTM SA/A234                    : WPB, WP5, WP9. WP11, WP22, WP91

ASME/ASTM SA/A403                    : WP304/L, WP316/L, WP317/L, WP321, WP347

ASME/ASTM SA/A420                    : WPL6

ASME/ASTM SA/A815                    : S31803, S32750, S32760

ASME/ASTM SA/A860                    : WPHY42, WPHY44, WPHY46, WPHY52, WPHY60, WPHY65, WPHY70

* Special material such as Monel, Inconel, Cu-Ni are available on request.

Specifications: NACE, SAMSS, MESC, DGS, KOC, KNPC, NORSOK, etc.

Certification : EN10204 3.1 or 3.2 by IACS approved inspection bodies.

Coating & Services: Three Layer Poly Ethylene/ Propylene (3LPE/ 3LPP), Cement Mortar Lining, Coal Tar Enamel (CTE), Sandblasting and Primer coating can be provided.
