Type : Socket Weld and Nominal Pipe Thread ( NPT )

 Size: 1/8” – 4” ( Upto 6” available on request).

Pressure Rating : 2000 lbs, 3000 lbs, 6000 lbs, 9000 lbs

Dimension & Tolerances : ASME/ANSI B16.11, BS3799, MS SP79/SP83/SP95 Threaded according to ASME B1.20.1

Material                                               Grade

ASME/ASTM SA/A105                    : N

ASME/ASTM SA/A182                    : F304/304L, F316/316L, F51, F60, F53, F55

ASME/ASTM SA/A350                    : LF2

ASME/ASTM SA/A694                    : F42, F52, F60, F65, F70

* Special material such as Monel, Inconel, Cu-Ni are available on request.

Specifications: NACE, SAMSS, MESC, DGS, KOC, KNPC, NORSOK, etc.

Certification: EN10204 3.1 or 3.2 by IACS approved inspection bodies.

Finishing : Black, hot dip galvanizing, electro plating Stainless Steel: Pickled and Passivated
